Access Tower
TThe SMI Access Tower uses a hydraulic system to lower the entire fan gun to ground level, providing full access to components without climbing. This allows for faster servicing and easier adjustments during snowmaking operations.
The tower can also remain lowered during operation, providing improved snowmaking angles in windy conditions. The fan head can oscillate in any direction regardless of tower height, allowing flexible snow placement.
When greater coverage and hang time are needed, the tower can be raised to its full height or positioned at intermediate elevations, depending on snowmaking requirements.
The Access Tower is compatible with automated fan guns.
How It Works
The Access Tower uses a hydraulic system to lower the mounted fan gun from its elevated position to ground level. Using simple controls, the entire snow gun lowers to waist-to-shoulder height, allowing full 360-degree access to all components.
After servicing, operators can:
Raise the tower to full height for maximum coverage
Set the tower at intermediate heights
Operate the snow gun in the lowered position or any height
This flexibility allows operators to adjust snowmaking strategy based on terrain and weather.
